ChannelPlus DA-520A Bidirectional RF Amplifier
Erhältlich
Normaler Preis
$19.99 USD
$300.00
Speichern
$280.01
(93%aus)
Versand wird an der Kasse berechnet.
Hurry, Only 1 left!
You have got FREE SHIPPING
Expected Delivery on - .
1
ChannelPlus DA-520A Bidirectional RF Amplifier
PRODUCT DETAILS
The Model DA-520A Bi-directional RF Amplifier provides 20 dB of gain in a CATV or antenna system. The Model DA-520A has bi-directional capabilities with a 5-40 MHz bandwidth return path. This allows compatibility with interactive CATV set top boxes. A 12 VDC Model 999-017-01 power supply is included.
Specifications:
* 54 MHz to 1 GHz forward bandwidth
* 5 MHz to 40 MHz reverse bandwidth
* 1.5 dB gain flatness
* Maximum input level 30 dBmv
* Dimensions: 3.5" W x 1.2" H x 2.5" D
